Maximum buoyancy

For the very heaviest loads, there are our container pontoons. Suitable for loads over 120 tons! And both our pontoons and couplings are fully DNV-GL certified.

van-schie-containerponton-12-meter

Van Schie believes more is possible than what is often thought possible. That’s why the Van Schie team developed the container pontoons with the unique coupling system. This allows the pontoons to be easily transported and used more frequently. Moreover, they have the advantage that they can be deployed as large as needed.

Van Schie provides occasional compositions in any form. Whether you need an assembly with a slot in the middle (catamaran assembly), or a specific working island, Van Schie makes it possible! We are also happy to supply spud poles, winches, bollards and, of course, much more, to ensure that working on your project is pleasant, efficient and safe. Én Van Schie can relieve you of all your worries by offering stability and strength calculations.

Unique specs of the container pontoon:

  • 6 or 12 meters long;
  • Easily transported by axle;
  • Faster assembly and disassembly thanks to efficient coupling system;
  • Available at home and abroad;
  • Many accessories for safe and efficient work;
  • Van Schie’s own innovation;
  • DNV-GL certified

Specifications

The pontoon is a steel (ST235 JR/Grade A) fully welded box-shaped body. The thickness of the steel on the deck and bottom is 8 mm, and the sheet piles are 6 mm thick. The pontoon is composed of three watertight compartments, each equipped with a manhole. Ten cornerblocks (twistlock type) were installed on the pontoon for attaching all possible facilities such as winches, etc.

See more specifications and accessories? Then download our product sheet. But know that our pontoon experts are eager to tell you more.

van-schie-containerponton-12-meter
Container pontoon 12 mtr
Length
11,980 mm
Width
2,480 mm
Height
1,500 mm
Upper deck
8 mm
Weight
10,500 kg
Buoyancy at 300 mm freeboard
20,400 kg
Maximum deck load
12 tons / m2
Maximum load coupling
35 tons
Number of compartments
3
Approval drawing
Germanischer Lloyd
van-schie-containerponton-6-meter
Container pontoon 6 mtr
Length
5,980 mm
Width
2.480
Height
1,500 mm
Upper deck
8 mm
Weight
6,200 kg
Buoyancy at 300 mm freeboard
7,250 kg
Maximum deck load
12 tons / m2
Maximum load coupling
35 tons
Number of compartments
2
Approval drawing
Germanischer Lloyd
